Fused Silica Plates

noe-laboratory-components-1099942823
Fused Silica Plate

Newcastle Optics supply UV Fused Silica plates and substrates. The UV Fused Silica material has excellent purity, no fluorescence and high transmission in the DUV, UV and IR region from 180nm to 2000nm. The optical grade Fused Silica is virtually bubble free with resistance to chemicals, withstanding high temperatures and thermal shock. We process many grades from global manufactures.

These can be large Fused Silica plates for industrial scientific applications, to precision beamsplitters. Stock thicknesses in the Fused Silica plates range are from 0.50mm to 6mm but these can be made a lot thinner with thicknesses below 0.50mm. A range below this is UV Fused Silica coverslips with thicknesses down to 0.10mm thick.

For inquiries or to place an order, please reach out to our dedicated sales team.

Buy direct from stock
Get a quote for specific requirements

Option A

  • Material:
  • UV Fused Silica - Spectrosil 2000®
  • Diameter Tolerance:
  • +/-0.10mm
  • Thickness Tolerance:
  • +/-0.10mm
  • Edge Finish:
  • Fine ground & chamfered
  • Surface Quality:
  • 40/20 Scratch/Dig
  • Surface Flatness:
  • 3-5 Fringes (@633nm) per 25mm x 25mm
  • Parallelism:
  • ≤ 5 Arc mins

Option B

  • Material:
  • NA
  • Diameter Tolerance:
  • NA
  • Thickness Tolerance:
  • NA
  • Edge Finish:
  • NA
  • Surface Quality:
  • NA
  • Surface Flatness:
  • NA
  • Parallelism:
  • NA
  • Dimensions:
  • Squares/Rectangles 1mm x 1mm to 300mm x 300mm
  • Thickness Range:
  • 0.1mm to 50mm (subject to dimension)
  • Dimension/Thickness:
  • Tol to 0.02mm
  • Edge Finish:
  • Ground or polished
  • Surface Quality:
  • 80/50 to 20/10 scratch/dig
  • Surface Flatness:
  • Up to lambda 10 (@633nm)
  • Parallelism:
  • Up to 10 seconds
  • Material Options:
  • Corning HPFS 7980, KrF & ArF grade, Commercial Grade UV Silica & Heraeus Spectrosil 2000®, Heraeus Suprasil® I,
    2 grade A & B, 311, 312, 3001, 3002
  • Coating Options:
  • AR coatings from 193nm to 2000nm
  • Options:
  • Edges polished, wedges, shapes, drilled holes & bevelled angles

Buy direct from stock…

For discount pricing for stock parts over 10+ and volume/OEM quantities, please request a quote, where you can upload drawings and specifications. You can also add the below items to the quote by selecting 11 or more and clicking add to quote.
View Basket
View Quote

Part No.

  • SPEC10X10X1

Description

  • Fused Silica Plates

Diameter

  • 10mm X 10mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£10.80

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • SPEC12X12X1

Description

  • Fused Silica Plates

Diameter

  • 12mm X 12mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£13.50

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • SPEC15X15X1

Description

  • Fused Silica Plates

Diameter

  • 15mm X 15mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£15.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • SPEC20X20X1

Description

  • Fused Silica Plates

Diameter

  • 20mm X 20mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£16.30

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • SPEC25X25X0.5

Description

  • Fused Silica Plates

Diameter

  • 25mm X 25mm

Thickness

  • 0.5mm

Quantity

Unit Price (1-10) excl. VAT

£24.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • SPEC25X25X1

Description

  • Fused Silica Plates

Diameter

  • 25mm X 25mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£20.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • SPEC25X25X2

Description

  • Fused Silica Plates

Diameter

  • 25mm X 25mm

Thickness

  • 2mm

Quantity

Unit Price (1-10) excl. VAT

£23.50

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • SPEC25X25X3

Description

  • Fused Silica Plates

Diameter

  • 25mm X 25mm

Thickness

  • 3mm

Quantity

Unit Price (1-10) excl. VAT

£25.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • SPEC30X30X1

Description

  • Fused Silica Plates

Diameter

  • 30mm X 30mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£28.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • SPEC5X5X1

Description

  • Fused Silica Plates

Diameter

  • 5mm X 5mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£9.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF
