Fused Quartz Plates

noe-glass-factory-2002723022-1

Newcastle Optical supply Fused Quartz Plates from a standard stock range or custom made dimensions and options. Fused Quartz plates are widely used for industry and science for its optical and mechanical properties. These properties make it resistant to chemicals, withstand high temperatures and thermal shock.

Newcastle Optical supply Fused Quartz Plates from a standard stock range or custom made dimensions and options. Fused Quartz plates are widely used for industry and science for its optical and mechanical properties. These properties make it resistant to chemicals, withstand high temperatures and thermal shock.

For inquiries or to place an order, please reach out to our dedicated sales team.

Buy direct from stock
Get a quote for specific requirements

Option A

  • Material:
  • Fused Quartz
  • Diameter Tolerance:
  • +/-0.20mm
  • Thickness Tolerance:
  • +/- 0.10mm
  • Edge Finish:
  • Fine ground
  • Surface Quality:
  • 60/40 Scratch/Dig
  • Surface Flatness:
  • 3-5 Fringes (@633nm) per 25mm x 25mm
  • Parallelism:
  • ≤ 5 Arc mins

Option B

  • Material:
  • NA
  • Diameter Tolerance:
  • NA
  • Thickness Tolerance:
  • NA
  • Edge Finish:
  • NA
  • Surface Quality:
  • NA
  • Surface Flatness:
  • NA
  • Parallelism:
  • NA
  • Dimensions:
  • Squares/Rectangles 1mm x 1mm to 500mm x 500mm
  • Thickness Range:
  • 0.10mm to 50mm (Subject to dimension)
  • Dimension/Thickness:
  • Tol up to 0.02mm
  • Edge Finish:
  • Ground or polished
  • Surface Quality:
  • 80/50 to 20/10 scratch/dig
  • Surface Flatness:
  • Up to lambda 10 (@633nm)
  • Parallelism:
  • Up to 10 seconds
  • Material Options:
  • HOQ310, Commercial Grade Quartz, Infrasil & GE124
  • Coating Options:
  • AR coatings
  • Options:
  • Edges polished, wedges, shapes, drilled holes & bevelled angles

Buy direct from stock…

For discount pricing for stock parts over 10+ and volume/OEM quantities, please request a quote, where you can upload drawings and specifications. You can also add the below items to the quote by selecting 11 or more and clicking add to quote.
View Basket
View Quote

Part No.

  • QP100X100X1

Description

  • Fused Quartz Plate

Diameter

  • 100mm X 100mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£79.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP100X100X2

Description

  • Fused Quartz Plate

Diameter

  • 100mm X 100mm

Thickness

  • 2mm

Quantity

Unit Price (1-10) excl. VAT

£76.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP100X100X3

Description

  • Fused Quartz Plate

Diameter

  • 100mm X 100mm

Thickness

  • 3mm

Quantity

Unit Price (1-10) excl. VAT

£80.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP10X10X1

Description

  • Fused Quartz Plate

Diameter

  • 10mm X 10mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£7.90

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP12X12X1

Description

  • Fused Quartz Plate

Diameter

  • 12mm X 12mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£8.10

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP150X150X1

Description

  • Fused Quartz Plate

Diameter

  • 150mm X 150mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£112.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP150X150X10

Description

  • Fused Quartz Plate

Diameter

  • 150mm X 150mm

Thickness

  • 10mm

Quantity

Unit Price (1-10) excl. VAT

£325.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP150X150X2

Description

  • Fused Quartz Plate

Diameter

  • 150mm X 150mm

Thickness

  • 2mm

Quantity

Unit Price (1-10) excl. VAT

£100.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP150X150X3

Description

  • Fused Quartz Plate

Diameter

  • 150mm X 150mm

Thickness

  • 3mm

Quantity

Unit Price (1-10) excl. VAT

£119.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP150X150X4

Description

  • Fused Quartz Plate

Diameter

  • 150mm X 150mm

Thickness

  • 4mm

Quantity

Unit Price (1-10) excl. VAT

£160.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP150X150X5

Description

  • Fused Quartz Plate

Diameter

  • 150mm X 150mm

Thickness

  • 5mm

Quantity

Unit Price (1-10) excl. VAT

£195.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP150X150X6

Description

  • Fused Quartz Plate

Diameter

  • 150mm X 150mm

Thickness

  • 6mm

Quantity

Unit Price (1-10) excl. VAT

£210.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP15X15X1

Description

  • Fused Quartz Plate

Diameter

  • 15mm X 15mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£8.50

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP20X20X1

Description

  • Fused Quartz Plate

Diameter

  • 20mm X 20mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£9.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP25X25X1

Description

  • Fused Quartz Plate

Diameter

  • 25mm X 25mm

Thickness

  • 1mm

Quantity

Unit Price (1-10) excl. VAT

£9.20

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF

Part No.

  • QP25X25X2

Description

  • Fused Quartz Plate

Diameter

  • 25mm X 25mm

Thickness

  • 2mm

Quantity

Unit Price (1-10) excl. VAT

£14.00

* You have selected 10+ stock parts. Please add to quote for discount pricing over 10+ and volume/OEM quantities.

Download Datasheet PDF
